Phase-Cut Dimmer

Dimmer Switch for Dimmable LED UK Rotary

High compatibility with most bulbs on the market
Excellent linearity dimming function
Support to adjust the lowest brightness level
Overload and overtemperature protection
Low standby power consumption
1-Way or 2-Way control

SKU： D-H-DUK020M 分类： Phase-Cut Dimmer

Model No.	Rated Voltage	Power Supply	Max.Load	Min.Load	DimmingMethod	Application	Dimension L×W×H (mm)	Remark
Model No.	Rated Voltage	Power Supply	LED/lncandescent	LED/lncandescent	DimmingMethod	Application	Dimension L×W×H (mm)	Remark
DUK020T1-200 (Promotion Version)	220-240V, 50Hz	Live wire	200W/250W	3W/15W	Phase cut (Trailing)	1-Way or 2-Way	60.5x23x44	Triac
DUK020M1-200	220-240V, 50Hz	Live wire	150W/200W	3W/15W	Phase cut (Trailing)	1-Way or 2-Way	60.5x23x44	Mos
DUK020M1-300	220-240V, 50Hz	Live wire	200W/300W	3W/15W	Phase cut (Trailing)	1-Way or 2-Way	60.5x23x44	Mos

Listed	CE, ENERGY STAR, ERP, ETL, FCC, PSE, ROHS, SAA
